C1000-162 IBM Security QRadar SIEM V7.5 Analysis Questions and Answers

 Understanding Offense Management: In QRadar, offenses are generated based on predefined rules and correlations. When legitimate traffic is identified as an offense, it's essential to adjust configurations to prevent future false positives.

 Managing Legitimate LDAP Traffic:

Building Blocks: QRadar uses building blocks to group similar types of data. The BB

Definition: LDAP Servers building block is used to identify and manage LDAP servers within the network.

Excluding Legitimate Traffic: By adding the IP address of the legitimate LDAP server to this building block, QRadar will recognize the traffic as expected and exclude it from generating offenses.

 Implementation Steps:

Navigate to the QRadar console.

Go to the Admin tab and select Building Blocks.

Find and edit the BB

Definition: LDAP Servers building block.

Add the IP address of the LDAP server to this building block.

 Reference Confirmation: According to IBM QRadar documentation, adding the IP address of the LDAP server to the appropriate building block (BB

Definition: LDAP Servers) is the recommended method to handle such scenarios.

A Quick filter search in IBM Security QRadar SIEM operates on raw event or flow data. This type of search allows users to rapidly filter through large volumes of data to find specific events or flows of interest without the need for complex query syntax. Quick filter searches are particularly useful for conducting initial analyses or when looking for specific indicators within the raw data streams. The ability to search directly on raw event or flow data enables analysts to work with the most granular level of information available, facilitating detailed investigations and the identification of subtle patterns or anomalies that might indicate security issues .

To search offense data on the By Networks page, an analyst can use the options "Events/Flows" to filter based on the types of data points, and "Network" to specify the network they want to search for. This allows for a focused search on specific networks and types of data​​​​.

For pie charts in the Pulse app of QRadar, the available aggregation types include "Total" and "Average." These aggregation types allow for the representation of data in a manner that summarizes the total sum of the data points or their average value, respectively, providing insightful and concise visualizations of the data within the Pulse app dashboards. This information is implied from the general capabilities of dashboard items in QRadar, as detailed in the provided documentation, which typically includes such aggregation options for data visualization​​.

Pie Chart Logic: Pie charts represent proportions of a whole.expand_more QRadar Pulse supports the following aggregations suitable for this:

Total (Sum): Calculates the sum of a selected field's values, displaying each slice relative to the whole.

First: Takes the first value encountered in a field, useful for categorical data to show initial distribution.

Adding indexed properties to QRadar can significantly improve the efficiency of searches by reducing the size of the data set required to locate matches for non-indexed search values. Indexing creates references to unique terms in the data and their locations, which means that the search engine can filter the data set by indexed properties first, eliminating irrelevant portions of the data set and thereby reducing the overall volume of data that needs to be searched​​.

When deleting a generated content report in QRadar, all reports that were generated from the report template are deleted, but the report template itself is retained. This ensures that the structure for generating future reports remains intact, while only the instances of reports generated from that template are removed​​.

Event Details Page in QRadar: The event details page in QRadar provides comprehensive information about each event, including metadata, payload, and correlation details.

Checking Fully Matched Rules:

The event details page includes a section that lists all the rules that were fully matched for that specific event.

This information is crucial for analysts to understand why an event was flagged and how it contributes to the overall offense.

Navigating to Event Details:

To view the event details page, an analyst can click on the event from the offense details or directly from the event list.

Within the event details, the matched rules are typically listed under the "Rules" or "Correlation" section.

Reference Confirmation: According to IBM QRadar documentation, the event details page is the location where analysts can see which rules were fully matched for a specific event.

References:

IBM QRadar documentation on event investigation and details page layout confirms that fully matched rules are displayed on the event details page .

X-Force Exchange: The primary repository for contributed QRadar content, including compliance-focused content packs.

HIPAA Packs: Likely contain:

Predefined searches: Relevant to HIPAA monitoring and auditing

Reports: To generate structured documentation for compliance

Custom Rules: To detect potential HIPAA-related violations

Custom properties: To enhance event/flow data for HIPAA context

Other Options (less suitable):

Use Case Manager: Broader purpose, might include HIPAA use cases

Pulse App: Primarily dashboard oriented, not focused on content distribution

IBM Fix Central: Focuses on software fixes, not compliance content

References:

IBM X-Force Exchange: https://exchange.xforce.ibmcloud.com/hub  (Search for HIPAA)

The magnitude rating of an offense in QRadar is calculated based on relevance, severity, and credibility. Relevance determines the impact on the network, credibility indicates the integrity of the offense, and severity represents the level of threat. QRadar uses complex algorithms to calculate and periodically re-evaluate the offense magnitude rating​​.

Event Details Page Overview: The Event Details page in QRadar provides in-depth information about each event that is logged. This includes various parameters that help in the analysis and investigation of security incidents.

Configured Parameters:

Event Processor UUID: Unique identifier for the event processor, generally used for internal tracking.

High Level Category: Represents the general category of the event, useful for quick identification and filtering.

Log Source Time: The timestamp indicating when the log was generated by the source.

Log Source Group: A grouping of log sources for organizational purposes.

Relevance of High Level Category: The High Level Category is a crucial parameter found in the Event Details page, as it provides a broad classification of the event type, aiding in quick understanding and categorization of events.

Reference Confirmation: According to IBM QRadar documentation, the High Level Category is prominently featured on the Event Details page, making it the correct answer.

References:

IBM QRadar documentation on event analysis and Event Details page layout.

Common Rules: The foundation of QRadar's event analysis. They operate on structured events representing activity from various log sources.

Event Processor: Responsible for normalizing and categorizing raw log data from various sources into structured QRadar events.

On the Offenses tab within QRadar, the "Offense Type" column explains the cause of the offense. The offense type is determined by the rule that triggered the offense, and it dictates the kind of information displayed in the Offense Source Summary pane. This helps analysts understand the nature and origin of the offense, facilitating more effective investigation and response actions​​.

Indexing Principle: QRadar creates indexes on default properties to quickly locate data matching your queries.

Lookup vs. Scan: Instead of scanning all raw data, QRadar utilizes the index like a 'phonebook' for targeted lookups.

Optimization: Searching using indexed properties dramatically decreases the amount of data QRadar needs to process.

Understanding Reference Data Collections in QRadar: In IBM QRadar, reference data collections are used to store data that can be reused across various rules, searches, and reports. Each type of reference data collection has a specific use case and structure.

Types of Reference Data Collections:

Reference Map: Stores key-value pairs where each key is unique and maps to a specific value.

Reference List: Stores a list of values without any keys.

Reference Table: Stores multiple key-value pairs where each key can have multiple values.

Reference Set: Stores a set of unique values without any keys.

Use Case for Reference Map: When you need to correlate a unique key to a specific value, a reference map is the appropriate data structure. It allows for efficient lookups and associations between keys and their corresponding values.

Reference Confirmation: According to IBM QRadar documentation, a reference map is explicitly designed to correlate unique keys to values, making it the correct choice for such requirements.

References:

IBM QRadar documentation on reference data collections confirms the use of a reference map for correlating unique keys to values.

References:

http://www.ibm.com/support/knowledgecenter/en/SS42VS_7.2.7/com.ibm.qradar.doc/shc_qradar_comps.html

QRadar supports generating reports in various file formats, including PDF, HTML, XML, and XLS. These formats provide flexibility in how reports are viewed and shared, catering to different needs and preferences for report presentation and analysis​​.

Offense chaining in IBM Security QRadar SIEM V7.5 is based on the offense index field specified in the rule. This means that if a rule is configured to use a specific field, such as the source IP address, as the offense index field, there will only be one offense for that specific source IP address while the offense is active. This mechanism is crucial for tracking and managing offenses efficiently within the system​​.

Searchable Columns: In QRadar's "My Offenses" and "All Offenses" tabs, you can search by:

Source IPs: Filter offenses based on the originating IP address. Id: Search using the unique offense ID number.

Incorrect Options:

Impact, Relevance, Weight: These are offense attributes, but you often filter by them rather than directly searching within the column data.

References:

IBM QRadar Documentation - Searching for Offenses https://www.ibm.com/docs/en/qradar-on-cloud?topic=searches-searching-offenses-my-offenses-all-offenses-pages

To check the offenses triggered and mapped to the MITRE ATT&CK framework using the Use Case Manager app, an analyst can navigate through the Offenses tab, click on All Offenses, and then utilize the All Offenses Summary toolbar to display rules contributing to an offense. This process allows for an investigation into how offenses correlate with the MITRE ATT&CK framework. However, the exact option "Detected in timeframe" is not explicitly mentioned in the provided documentation, and the described procedure offers a broader approach to reviewing offenses and their associated rules within the MITRE ATT&CK context​​.

Context Menu: Right-clicking on an IP address in the Offense Summary window offers quick investigation actions.

IP-Related Tools: WHOIS and DNS Lookups are essential tools for:

WHOIS: Retrieving IP registration information (owner, contact details, etc.). DNS: Resolving domain names associated with the IP.

To perform an IP address X-Force Exchange Lookup in QRadar, you can follow these steps2:

Select the Log Activity or the Network Activity tab.

Right-click the IP address that you want to view in X-Force Exchange.

Select More Options > Plugin Options > X-Force Exchange Lookup to open the X-Force Exchange interface2.

The procedure to perform an IP address X-Force Exchange Lookup in QRadar involves selecting either the Log Activity or the Network Activity tab, right-clicking the IP address of interest, and then navigating through More Options > Plugin Options > X-Force Exchange Lookup to access the X-Force Exchange interface​​.

Time Series Charts in QRadar: Time series charts visualize how event or flow data changes over time. They are primarily used to spot trends and anomalies.

Interactivity: QRadar's time series charts allow zooming, panning, and hovering to see specific data points. This helps analysts drill down into patterns.

Search-Based: Time series charts always reflect the results of a search query. Changing the time range or refining the search alters the chart.

Inaccurate Statements

A. Static time series: QRadar's charts are not static; the interactivity is key.

C & D. Export Time: These focus on data export, which isn't directly related to the nature of time series charts themselves.

References

IBM QRadar Documentation - Time Series Charts: https://www.ibm.com/docs/en/qradar-common?topic=pulse-aggregating-data-create-time-series-chart

In IBM Security QRadar SIEM V7.5, the feature that utilizes existing asset profile data to define unknown server types and assign them to server definitions in building blocks and in the network hierarchy is known as "Server Discovery." This feature grants permission to discover servers, thereby enabling administrators to identify and classify various server types within their network infrastructure, enhancing the overall asset management and security posture​​.

Understanding Offense Creation in QRadar: QRadar SIEM generates offenses based on the correlation of various types of information to detect potential security threats and incidents.

Analyzed Information for Offense Creation:

Incoming Events and Flows: QRadar collects and analyzes incoming log events and network flows to identify suspicious activities.

Asset Information: Information about the assets within the organization, including their roles and vulnerabilities, is crucial for accurate threat detection.

Known Vulnerabilities: QRadar uses data about known vulnerabilities to correlate events and determine if a potential threat is exploiting these vulnerabilities.

Relevance of the Selected Information: The combination of incoming events, flows, asset information, and known vulnerabilities provides a comprehensive view that helps QRadar accurately identify and correlate potential security incidents, resulting in the creation of offenses.

Reference Confirmation: According to IBM QRadar documentation, the correct combination of analyzed information for creating offenses includes incoming events and flows, asset information, and known vulnerabilities.

References:

IBM QRadar documentation on offense creation and analysis confirms the use of incoming events, flows, asset information, and known vulnerabilities.

Dashboard Data Refresh: Most widgets on QRadar dashboards typically refresh the displayed data every minute by default.

Customization: In some cases, you might be able to configure this refresh interval depending on the widget type.

Understanding Scatter Charts in QRadar Pulse: QRadar Pulse is a visualization application used to create and view different types of charts for better data analysis and interpretation.

Types of Y-Axis:

Linear Axis: This type of axis displays data points at equal intervals. It's suitable for evenly distributed data and shows trends in a straightforward manner.

Logarithmic (Log) Axis: This axis type displays data on a logarithmic scale, which is useful for data that covers several orders of magnitude or for data that grows exponentially.

Selection for Scatter Charts: When creating scatter charts in QRadar Pulse, the application allows users to choose between linear and logarithmic (log) Y-axis types to best represent their data.

Reference Confirmation: According to IBM QRadar documentation, both linear and logarithmic Y-axis types are supported for scatter charts in the Pulse app, making them the correct answers.

References:

IBM QRadar documentation on Pulse app charting options confirms the availability of linear and logarithmic Y-axis types.

A "Flow Bias" Quick Search can be performed from the Network Activity tab in QRadar, providing insights into network flows and potential anomalies or biases in the traffic patterns​​.

To identify events that were missed by the Custom Rule Engine (CRE) in IBM Security QRadar SIEM, an analyst would primarily look for "Log Only Events sent to a Data Store" and "High Level Category Unknown Events." Log Only Events are those that are stored directly without being processed by the CRE, indicating they might have been overlooked or not matched by any existing rules. High Level Category Unknown Events are those that do not fit into any of the predefined categories in QRadar, suggesting that the CRE might not have rules to handle or categorize these events properly. These types of events are crucial for analysts to review to ensure that no significant incidents are missed and to refine the rule set for better detection in the future.

Selecting "False Positive" from the right-click menu in the Log Activity tab opens a window that enables users to tune out events that are known to be false positives, preventing them from generating offenses. This feature is crucial for minimizing noise and focusing on genuine threats, thereby enhancing the efficiency of threat detection and response processes within QRadar​​.

Building Blocks in QRadar are foundational elements that are used to construct more complex rules. They are essentially a collection of conditional tests or criteria that define specific behaviors, characteristics, or patterns within the network data but do not, by themselves, trigger any responses or actions when those conditions are met.

Building Blocks are designed to be reused in multiple rules, making rule creation more efficient and standardized. For example, a Building Block might define a set of common malicious IP addresses or unusual traffic patterns. This Building Block can then be incorporated into several different rules that might deal with various types of threats, each of which requires identifying traffic from or to these malicious IPs as part of their logic.

The reusability of Building Blocks ensures that changes to common criteria, such as updating the list of malicious IP addresses, only need to be made in one place. This approach enhances the maintainability and consistency of the rule set within QRadar, making the system more agile and responsive to changes in the threat landscape.

Building Blocks are a powerful feature within QRadar that promote modularity and efficiency in rule creation, helping organizations tailor their threat detection capabilities to their specific needs without requiring actions or responses to be defined within these foundational elements themselves.

The MITRE heat map in the Use Case Manager app within QRadar uses several factors to determine the colors displayed, among which the number of rules mapped to MITRE ATT&CK tactics and techniques and the level of mapping confidence are crucial. These factors help visualize the coverage and reliability of rule mappings against the comprehensive MITRE ATT&CK framework, aiding in the identification of potential gaps or areas for improvement in threat detection capabilities​​.
